Albert Double Stage Hydraulic Vane Pump for Industrial Applications Tokimec Sqp Type Sqp43 Sqp42 Sqp41 Sqp32 Sqp31 Sqp21

In the high-stakes world of precision machining, where micron-level accuracy is required along with increasing energy costs, the hydraulic system can no longer be an afterthought. It must be a source of reliability, efficiency, and quiet operation. The TOKIMEC SQP series double pump configuration is engineered to meet these exacting demands, making it the ideal hydraulic heart for a wide range of machine tools, including machining centers, grinders, and CNC lathes.

Product Description

Applications

Machine tools require hydraulic power for essential functions such as spindle clamping, tool changer operation, chuck clamping, and tailstock advancement. These functions often have different requirements: some need high flow for quick movement, while others require sustained high pressure for holding. A conventional single pump must be sized for the highest flow demand, leading to inefficient operation and excessive heat and noise during low-flow periods. The SQP double pump effectively addresses this issue by distributing these tasks between its two pump sections.

One section, typically the larger unit, is designed for high-flow, low-pressure tasks such as indexing the tool changer arm or rapid traverse of a tailstock. The second, smaller section is specifically calibrated to supply consistent, high-pressure power needed for securely holding a tool in the spindle or a workpiece in the chuck. This intelligent division of labor is controlled through efficient load-sensing systems, ensuring each pump section delivers only the required flow and pressure, significantly reducing energy use and heat production.

Beyond efficiency, the SQP double pump is designed to offer the stability needed for precise operations. Its advanced engineering reduces pressure fluctuations and flow disturbances, resulting in smoother and quieter performance of hydraulic systems. This leads to better surface quality and higher part consistency. Additionally, the pump's quiet operation is a key feature of the SQP series, contributing to a more pleasant working environment and compliance with modern noise regulations.

Model Designation

(F3-)	SQP32	-35	-17	-86	CD	(F)	-(LH)	-18
Infuse front, oil intermiscibility	Series	Displacement code of shaft end pump	Displacement code of cover end pump	Shaft type	Port positions	Installation type	Rotation	Design number
No-marking: Anti-wear hydraulic oil, Water glycol fluid or water-oil emulsions F3- phosphate ester fluid	SQP21	10, 12, 14, 15, 17, 19, 21, 25	2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 14	1-Belt key straight shaft 86-Heavy belt key straight shaft	See below	No-marking: Flange Mounting F-Foot Mountion	(Viewed from shaft end of pump) LH-Left hand for counter clockwise No marking-Rihgt hand for clockwise	18
	SQP31	21, 25, 30, 32, 35, 38, 45	2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 14
	SQP32	21, 25, 30, 32, 35, 38, 45	10, 12, 14, 15, 17, 19, 21, 25
	SQP41	42, 45, 50, 57, 60, 66, 75	2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 14
	SQP42	42, 45, 50, 57, 60, 66, 75	10, 12, 14, 15, 17, 19, 21, 25
	SQP43	42, 45, 50, 57, 60, 66, 75	21, 25, 30, 32, 35, 38, 45

USgpm Flow(USgpm) at 1200r/min and 0.69MPa.

Noise Data

Outlet Positions (Viewed from cover end of pump)

Portpositions		Allseries(exceptSQP43)	SQP43series
No.1 outlet opposite inlet	AA	No.2 outlet 135°CCW from inlet	No.2 outlet opposite inlet
	AB	No.2 outlet 45°CCW from inlet	No.2 outlet 90°CCW from inlet
	AC	No.2 outlet 45°CW from inlet	No.2 outlet inline with inlet
	AD	No.2 outlet 135°CW from inlet	No.2 outlet 90°CW from inlet
No.1 outlet 90° CCW from inlet	BA	No.2 outlet 135°CCW from inlet	No.2 outlet opposite inlet
	BB	No.2 outlet 45°CCW from inlet	No.2 outlet 90°CCW from inlet
	BC	No.2 outlet 45°CW from inlet	No.2 outlet inline with inlet
	BD	No.2 outlet 135°CW from inlet	No.2 outlet 90°CW from inlet
No.1 outlet inline with inlet	CA	No.2 outlet 135°CCW from inlet	No.2 outlet opposite inlet
	CB	No.2 outlet 45°CCW from inlet	No.2 outlet 90°CCW from inlet
	CC	No.2 outlet 45°CW from inlet	No.2 outlet inline with inlet
	CD	No.2 outlet 135°CW from inlet	No.2 outlet 90°CW from inlet
No.1 outlet 90°CW from inlet	DA	No.2 outlet 135°CCW from inlet	No.2 outlet opposite inlet
	DB	No.2 outlet 45°CCW from inlet	No.2 outlet 90°CCW from inlet
	DC	No.2 outlet 45°CW from inlet	No.2 outlet inline with inlet
	DD	No.2 outlet 135°CW from inlet	No.2 outlet 90°CW from inlet

Technical Data

Series	Shaft end pump(No.1outlet)			Cover end pump(No.2outlet)			r/min Max.speed	Min.speed r/min
	Displacement code	Ml/r Geometric displacement	MPa Max. pressure	Displacement code	mL/r Geometric displacement	MPa Max. pressure
SQP21	10	32.5	As SQP2	2	7.5	As SQP1	As SQP Series single pumps	600
	12	38.3
	14	43.3		3	10.2
	15	46.7
	17	52.5		4	12.8
	19	59.2
	21	65.0		5	16.7
	25	79.2
SQP31	21	66.7	SQP3 As SQP3	6	19.2
	25	79.2		7	22.9
	30	95.0
	32	100		8	26.2
	35	109
	38	118		9	28.8
	45	140
SQP41	42	134	As SQP4	10	31.0
	45	140
	50	156		11	35.0
	57	178
	60	189		12	37.9
	66	207		14	44.2
	75	237
SQP32	21	66.7	As SQP3	10	32.5	As SQP2	As SQP Series single pumps	600
	25	79.2
	30	95.0		12	38.3
	32	100
	35	109		14	43.3
	38	118
	45	140		15	46.7
SQP42	42	134	As SQP4	17	52.5
	45	140
	50	156		19	59.2
	57	178
	60	189		21	65.0
	66	207
	75	237		25	79.2
SQP43	42	134	As SQP4	21	66.7	As SQP3	As SQP Series single pumps	600
	45	140		25	79.2
	50	156		30	95.0
	57	178		32	100
	60	189		35	109
	66	207		38	118
	75	237		45	140
USgpm Flow(USgpm) at 1200r/min and 0.69MPa
Permit surpassing the top pressure 10% instantaneous pressure, within 0.5 second.
